2001 Suzuki Grand Vitara DFC GEOSPEC Coated Rotor
Part Type:
Disc Brake Rotor
SKU:
604-01013
Axle:
Front
PCQ:
2
Description
- DFC GEOSPEC Coated Rotor - Blank
Features and Benefits
- Non-Directional Finish To Promote Faster Break-In And Smoother Stops
- 100% Precision Cut And Mill-Balanced For Smoother Stopping And Zero Vibration At Any Speed
- CNC-Machined To The Tightest Tolerances
- Original Equipment (OE) Vane Configuration To Ensure Proper And Maximum Heat Dissipation
- Designed To Meet The Same Form, Fit, And Function As OEM Brake Rotors
- Provides Superior Corrosion Protection Over Zinc / Conventional Painting
- Engineered With Premium G3000/G11H18 Iron Castings For Strength, Stability, And Durability
- Quality Tested To Ensure Long-Lasting Performance
- Ready To Install - No Additional Pre-Degreasing Preparation Needed (Saves Time And Money During Installation Process)
Product Specifications
| Description | Value |
|---|---|
| Inside Diameter | 108.4mm |
| Bolt Hole Quantity | 5EA |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Outside Diameter | 310mm |
| Disc Finish | Plain |
| Discard Thickness | 20mm |
| This product contains Antimony Oxide and other chemicals which is known in the State of California to cause cancer ( or reproductive problems). | |
| Height | 29.1mm |
| Overall Height | 29.1mm |
| Bolt Hole Diameter | 12.8mm |
| Description | Value |
|---|---|
| Solid Or Vented Type Rotor | Vented |
| Nominal Thickness | 22mm |
| Hat Finish | GEOSPEC Silver Grey |
| Surface Type | Smooth |
| Rust Resistant Coating | Yes |
| Stud/Lug Hole Diameter | 12.8mm |
| Center Hole Diameter | 108.4mm |
| Stud/Lug Hole Circle Diameter | 139.7mm |
| Stud/Lug Hole Quantity | 5 |
| Weight | 14.1LB |
